Description
Specifications:
- Max. Number of input cards: 10
- Max. Number of input channels: 40
- Max. Number of output cards: 3
- Max. Loading Capacity: 39,000,000 Pixel
- Max. Number of layers: 4
Description
As a pivotal component within NovaStar’s latest line of video wall splicers, the H5 excels with outstanding image quality and a specialized design crafted for fine-pitch LED displays. Offering versatility, the H5 can function either as an integrated splicer, merging video processing and control functions, or as a dedicated splicing processor. The unit’s modular and pluggable nature facilitates flexible configurations and the convenient “hot-swapping” of input and output boards. With its stellar features and dependable performance, the H5 proves its effectiveness across a wide array of applications.
HARDWARE FEATURES
- Two different types of 4K Sending Cards available:
- H_20xRJ45: Manages up to 13 million pixels
- H_16xRJ45: Manages up to 10.4 million pixels (incl. 2x OPT-Out)
- Different configurations possible on one Sending Card:
- 4x 2K×1K@60Hz
- 2x 4K×1K@60Hz
- 1x 4K×2K@60Hz
- Online monitoring for all input & output cards
- “Hot-Swap” function for all in- & output cards
- IP input card H_2xRJ45 supports up to 100 IP cameras incl. input mosaic
- Automatic decryption of HDCP protected sources
- multi-screen management
- web control
Additional information
| Weight | 35 kg |
|---|---|
| Dimensions | 62 × 54 × 30 cm |
